When you are working a lap, clear communication from race control matters. MYLAPS X2 RaceLink Club brings live personal and track flag signals into the cockpit when paired with Garmin Catalyst 2 through the required in-car flagging Y-cable at a supported circuit.
Race-control information in the car
The onboard unit works with a track's MYLAPS X2 Race Control system. Instead of relying on an assumption that every circuit is equipped, check your event and track first. A compatible Catalyst 2 driving performance optimizer and the in-car flagging Y-cable are sold separately.
What it brings to a supported race day
- Live onboard flag signals: personal and track flags from race control can be presented in your compatible cockpit setup.
- Live GPS tracking: supplies position data for race-control monitoring.
- 10 Hz GPS updates: a fast position-update rate for circuit use.
- Up to 24 hours of backup battery life: specified battery endurance for a full day at the circuit, with approximately six hours required for a full charge.
- One year of service included: renewal fees may apply after the included subscription period.
- Speedhive app support: use the app for setup and subscription management.
Check compatibility before ordering
X2 RaceLink Club is not a timing transponder. It functions only with the MYLAPS X2 Race Control system. Ask your track or series organizer about system support and compliance before purchase. This listing is the RaceLink Club device and listed cables; Garmin Catalyst 2 and the dedicated in-car flagging Y-cable are separate.
Compatible Garmin devices
- Garmin Catalyst™ 2
What is included
- MYLAPS X2 RaceLink Club with one-year service plan
- M8 power cable
- M8 4-pin to USB cable
Specifications
| Garmin part number | 010-04823-00 |
|---|---|
| General | |
| Compatibility | MYLAPS X2 Race Control system (check compatibility with your event organizer or track) |
| Dimensions | 83 mm x 59.5 mm x 24 mm (3.3" x 2.4" x 1") |
| Weight | 0.26 lbs (120 g) |
| Battery lifetime (back up) | Up to 24 hours |
| Battery charging | 6 hours for full charge |
| Operating voltage | 7-18 VDC typical 12 V |
| Power consumption | 1.3 W, 110 mA@12 V |
| Operating temperature | 31 to 122 F (0 to 50 C) |
| Storage temperature | 31 to 86 F (0 to 30 C) |
| Shelf life storage mode | 6 months (when fully charged) |
| Shelf life non-storage mode | 1 month (when fully charged) |
| Humidity range | 10% to 90% relative |
| Positioning | -167 dBm, 72 channels |
| Sensitivity | 3 concurrent GNSS reception |
| Update rate GPS | 10 Hz |
| RF output | +20 dBm @ 2.4GHz ISM |
| Charging | 300 mA @ 5 VDC 150 mA @ 12 VDC |
| Protection class | IP 62 without connectors connected IP 64 with connectors connected |
| Protocol | CAN 2.0 |
| Baudrate | 1 Mbps (default), 500 or 250 Kbps |
| Termination | 120 Ohm software selectable |
Circuit-use warning
Garmin Catalyst 2 is intended only for recreational use in a circuit environment. Never use it on public roadways. Failure to follow this warning may result in an accident causing property damage, serious personal injury or death. You are responsible for using the device safely and prudently.
Garmin product details
Build a supported cockpit flagging system with PMB Performance. Confirm your event's MYLAPS setup, then match this RaceLink Club with Catalyst 2 and the correct Y-cable.
Product images and specifications supplied by Garmin. Product design and specifications may change as Garmin makes engineering improvements. Accessories and devices shown in feature illustrations are included only when named in the included-items list.
