Product details
The Wilwood forward-swing clutch kit places a 7:1 forged pedal in a hanging installation and supplies the hydraulic master and pull-type slave cylinders. Its 12.10-inch pedal arm provides a different mounting envelope from the floor version, while the footpad can be positioned laterally. The complete brake installation determines which Wilwood component is appropriate. Wilwood Engineering designs and manufactures disc brake systems, calipers, rotors, master cylinders, valves, fittings, and brake lines for motorsport, street-performance, and specialized applications. Bill Wood founded the company in 1977, and it is based in Camarillo, California.
Technical Details
- Manufacturer part number: 341-15170
- Material: Aluminum
- Finish: Black E-coat
- Pedal mounting: Forward swing / hanging
- Pedal ratio: 7:1
- Arm length: 12.10 inches
- Master cylinder: 260-1304; 3/4-inch bore
- Slave cylinder: 260-1333; pull type
- Weight: 4.750 lb
- Mount length: 12.89 in
Wilwood technical instructions DS-252 · Wilwood product specifications
Fitment & Compatibility
Supplied with 3/4-inch-bore integral-reservoir master cylinder 260-1304 and pull-type slave 260-1333. Verify overhead mounting support, clutch linkage direction, release stroke, and line routing. It is not the floor-mounted kit despite sharing its hydraulic components.
PMB Performance offers fitment support backed by more than 20 years of experience. Share the specifications of the matching assembly so the component can be checked in context.
