Product details
An adjustable-ratio throttle bellcrank equips this Wilwood floor-mounted three-pedal set for a front-engine linkage arrangement. Brake and clutch leverage can be set to 4.75, 5.25, or 5.75:1, with a standard balance bar dividing brake-pedal force between two master cylinders. Bill Wood founded Wilwood Engineering in 1977; the company is based in Camarillo, California. Wilwood designs and manufactures disc brake systems, from calipers and brake rotors to master cylinders, valves, fittings, and brake lines. Its motorsport, street-performance, and specialized components are chosen to suit the complete braking installation.
Technical Details
- Manufacturer part number: 340-16603
- Material: Aluminum
- Finish: Black E-coat
- Pedals: Brake, clutch, throttle
- Included throttle mechanism: Adjustable-ratio front-engine bellcrank
- Brake/clutch ratios: 4.75, 5.25, or 5.75:1
- Balance system: Standard detent bar
- Hydraulics: Master cylinders not included
- Weight: 7.880 lb
Wilwood technical instructions DS-252 · Wilwood technical instructions DS-1486 · Wilwood product specifications
Fitment & Compatibility
Suited to a fabricated installation using three 2.25-inch vertical-flange master cylinders, ordered separately. Verify throttle cable or rod routing, 3.75-5.75-inch pad spacing, and full brake and clutch stroke before choosing the final head positions.
PMB Performance brings over 20 years of parts and fitment experience. Contact us with the throttle linkage direction and floor mounting space for help checking this selection.
