Product details
A height-adjustable pedal head gives this Wilwood forward-swing replacement kit three leverage settings from 6.25:1 to 7:1. The brake arm, standard balance bar and clevis hardware update the specified earlier pedal assemblies; a complete mounting base is not included. Wilwood's range extends from calipers and brake rotors to master cylinders, valves, fittings, and brake lines, all selected to meet the requirements of a complete brake system. Founded by Bill Wood in 1977, Wilwood Engineering is based in Camarillo, California and designs and manufactures disc brake systems for motorsport, street-performance, and specialized uses.
Technical Details
- Manufacturer part number: 340-16412
- Material: Aluminum
- Finish: Black E-coat
- Pedal ratios: Three head positions spanning 6.25:1 to 7.00:1
- Bias mechanism: Standard balance bar
- Installation: Forward-mount pedal retrofit
- Weight: 1.740 lb
Wilwood technical instructions DS-252 · Wilwood product specifications
Fitment & Compatibility
For conversion of Wilwood 340-1287 and 340-13832 forward brake pedal assemblies. Check base condition, pushrod geometry, and foot clearance at the selected pedal-head position.
Over 20 years of parts experience stands behind PMB Performance's fitment assistance. Contact us with the component measurements and assembly information needed to check your application.
