Product details
This Wilwood forward pedal conversion combines an adjustable brake arm with Tru-Bar trunnion and clevis hardware. It changes the brake-side balance mechanism on compatible assemblies without supplying a replacement mounting base or clutch pedal. The complete brake installation determines which Wilwood component is appropriate. Wilwood Engineering designs and manufactures disc brake systems, calipers, rotors, master cylinders, valves, fittings, and brake lines for motorsport, street-performance, and specialized applications. Bill Wood founded the company in 1977, and it is based in Camarillo, California.
Technical Details
- Manufacturer part number: 340-16402
- Material: Aluminum
- Finish: Black E-coat
- Adjustment positions: Three head positions spanning 5.50:1 to 6.25:1
- Type: Forward-swing Tru-Bar brake pedal retrofit
- Included hardware: Trunnion and clevis conversion hardware
- Weight: 2.110 lb
Wilwood technical instructions DS-1102 · Wilwood product specifications
Fitment & Compatibility
Fits Wilwood 340-11295, 340-15072, 340-16350, 340-16382, 340-16383, and 340-3950 assemblies. Check the existing pedal identification, master-cylinder connections, and available travel before installing the conversion.
PMB Performance offers fitment support backed by more than 20 years of experience. Share the specifications of the matching assembly so the component can be checked in context.
