Product details
Wilwood's forward-hanging brake assembly places two master cylinders through the firewall and offers three pedal-head positions. Leverage ranges from 6.25:1 to 7:1, with a conventional detent balance bar allowing front-to-rear brake bias to be set separately. Wilwood Engineering designs and manufactures complete disc brake systems as well as calipers, brake rotors, master cylinders, valves, fittings, and brake lines. Based in Camarillo, California, it was founded by Bill Wood in 1977. The range serves motorsport, street-performance, and specialized applications, requiring each part to be matched to the system in which it operates.
Technical Details
- Manufacturer part number: 340-16379
- Material: Aluminum
- Finish: Black E-coat
- Mount Type: Swing; Forward
- Ratios: Three head positions spanning 6.25:1 to 7.00:1
- Bias bar: Conventional detent; optional remote adjustment
- Foot pad: Adjustable 1/2 in left or right
- Weight: 3.190 lb
Wilwood technical instructions DS-252 · Wilwood technical instructions DS-1465 · Wilwood product specifications
Fitment & Compatibility
Provide a supported firewall mounting area and two compatible 2.25-inch vertical-flange masters. Cylinders and an optional remote bias cable are separate. Recheck free travel and master-cylinder stroke after changing the vertical head or lateral foot-pad position.
