Product details
Wilwood pairs two 6.25:1 forward-swing pedals with a Tru-Bar linkage for separate brake and clutch circuits. The brake arm uses a fixed trunnion and spherical pushrod connections to divide force between two brake master cylinders; the clutch uses its own cylinder. Bill Wood founded Wilwood Engineering in 1977; the company is based in Camarillo, California. Wilwood designs and manufactures disc brake systems, from calipers and brake rotors to master cylinders, valves, fittings, and brake lines. Its motorsport, street-performance, and specialized components are chosen to suit the complete braking installation.
Technical Details
- Manufacturer part number: 340-15072
- Material: Aluminum
- Finish: Black E-coat
- Mount Type: Swing; Forward
- Pedal ratios: Brake 6.25:1; clutch 6.25:1
- Pedal lengths: 12.07 in each
- Balance bar: Tru-Bar; 7/16-20; 3/8-inch remote-adjuster end
- Weight: 5.100 lb
- Mount length: 12.57 in
Wilwood technical instructions DS-1102 · Wilwood technical instructions DS-1103 · Wilwood product specifications
Fitment & Compatibility
This configuration places the master cylinders forward of the hanging pedals. Confirm firewall support, reservoir access and master-cylinder stroke before choosing bores. It supersedes assemblies 340-3950 and 340-11295; cylinders and remote bias cable are separate.
PMB Performance brings over 20 years of parts and fitment experience. Contact us with the forward cylinder clearance and brake and clutch requirements for help checking this selection.
