Product details
This forward-facing swing pedal uses a single master cylinder connection and a 7:1 forged aluminum arm. It can operate the specified hydraulic clutch or tandem brake master without a separate balance-bar linkage. Bill Wood founded Wilwood Engineering in 1977; the company is based in Camarillo, California. Wilwood designs and manufactures disc brake systems, from calipers and brake rotors to master cylinders, valves, fittings, and brake lines. Its motorsport, street-performance, and specialized components are chosen to suit the complete braking installation.
Technical Details
- Manufacturer part number: 340-13834
- Material: Aluminum
- Finish: Black E-coat
- Mount Type: Swing; Forward
- Ratio: 7.0 to 1
- Pedal Length: 12.10 in
- Balance bar: None
- Foot-pad position: Laterally adjustable
- Weight: 1.980 lb
- Mount length: 12.89 in
Wilwood product specifications · Wilwood product guide FL369
Fitment & Compatibility
Check the master flange and pedal mounting dimensions. Four-wheel brakes must use a two-circuit tandem-outlet master; horizontal-flange units require adapter 250-3677, and all masters are selected separately.
PMB Performance brings over 20 years of parts and fitment experience. Contact us with the master-cylinder type, flange pattern and available pedal space for help checking this selection.
