Product details
This three-pedal floor assembly adds a throttle bell crank and linkage to the brake, clutch and accelerator controls. Wilwood specifies this version for front-engine routing, with fabricated steel pedal arms on an aluminum mounting frame. Wilwood Engineering designs and manufactures complete disc brake systems as well as calipers, brake rotors, master cylinders, valves, fittings, and brake lines. Based in Camarillo, California, it was founded by Bill Wood in 1977. The range serves motorsport, street-performance, and specialized applications, requiring each part to be matched to the system in which it operates.
Technical Details
- Manufacturer part number: 340-12411
- Material: Aluminum / Steel
- Finish: Black E-coat
- Mount Type: Floor; Forward
- Ratio: 5.25 to 1
- Pedal Length: 10.66 in
- Throttle hardware: Bell crank and linkage included
- Balance bar: Included
- Weight: 7.150 lb
- Mount length: 11.40 in
Wilwood technical instructions DS-252 · Wilwood technical instructions DS-907 · Wilwood product specifications
Fitment & Compatibility
Confirm the required throttle pull direction and travel before installation. The brake and clutch pedals use a nominal 5.25:1 ratio, and the included brake balance bar requires correctly selected master cylinders.
