Product details
Drilled 5/8-11 studs and a black E-coated finish identify this Wilwood front Starlite 55 hub. The Snap-Cap closes the hub snout, and the wheel and rotor attach on separate Wide 5 and eight-bolt patterns. Wilwood Engineering was founded by Bill Wood in 1977 and is based in Camarillo, California. Its disc-brake systems and components include calipers, brake rotors, master cylinders, valves, fittings and brake lines for motorsport, street-performance and specialized applications, with each component selected for the complete brake system.
Technical Details
- Manufacturer part number: 270-6735BD
- Material: Aluminum
- Finish: Black E-Coat
- Wheel bolt pattern: 5 x 10.25 in
- Wheel stud thread: 5/8-11
- Axle: Front
- Stud construction: Drilled coarse-thread studs
- Closure style: Snap-Cap
- Rotor interface: 8 x 7.00-inch bolt circle, standard offset
- Weight: 6.9 lb
- Inner bearing specification: 370-0431 (fitment reference)
- Outer bearing specification: 370-0432 (fitment reference)
Fitment & Compatibility
Compare the drilled 5/8-11 stud configuration with the existing hub rather than substituting by finish alone. The wheel circle is 5 x 10.25 inches, while the rotor attaches on an 8 x 7.00-inch circle; these are different mounting interfaces.
Manufacturer Documents
The photograph represents the product family. Match the ordered configuration using the part number and specifications above.
PMB Performance brings over 20 years of experience with brake components and fitment. Send us the installed kit number and relevant measurements if you need help confirming this part.
