Product details
The split XRZ hub is the axle-clamping component for either supported rotor-plate arrangement. Its 46-spline interface and five-bolt plate attachment distinguish it from earlier Gen II Sprint hubs. Wilwood Engineering has designed and manufactured disc brake systems since Bill Wood founded it in 1977. Its Camarillo, California operation supplies calipers, master cylinders, brake rotors, valves, fittings and lines for specialized, street-performance and motorsport applications. Each component must be chosen to match the complete brake system.
Technical Details
- Manufacturer part number: 270-17657
- Finish: Type III Anodize
- Rotor mounting arrangement: Adapter-Dynamic
- Hub-to-adapter attachment: 5x4.875; this is not the wheel bolt circle
- Compatible rotor-adapter output interface(s): 8 x 7.00, 8Lug-7.18; match the actual adapter and rotor
- Axle spline interface: 46-spline Sprint XRZ; match the specified DMI/Winters axle profile
- Package: One clamp-hub assembly; select the rotor adapter and rotor retention hardware separately
- Component: Sprint Inboard Hub - Dynamic
- Position in the specified assembly: Rear
- Material: Aluminum
Fitment & Compatibility
For the specified rear inboard racing axle and matching rotor adapter. Confirm the spline count and profile, axle clamp engagement, rotor alignment and caliper clearance. This part mounts the brake rotor; it is not an outboard wheel hub.
