Product details
This Wide 5 drive flange uses an internal ball-spline arrangement for a cambered rear axle. The steel assembly permits up to two degrees of misalignment and must match the 24-spline drive shaft and five-bolt hub. Wilwood Engineering is a Camarillo, California manufacturer founded by Bill Wood in 1977. Disc brake design and manufacturing extend across calipers, brake rotors, master cylinders, valves, fittings and brake lines. Parts for street-performance, specialized applications and motorsport must be selected to meet the requirements of the complete brake system.
Technical Details
- Manufacturer part number: 270-16183
- Component: Wide 5 Drive Flange 2-Deg
- Position in the specified assembly: Rear
- Material: Steel
- Finish: Plated
- Flange attachment reference: 5 x 3.98; this is not the wheel bolt circle
- Drive-shaft spline count: 24 splines
- Camber accommodation: Up to 2 degrees of misalignment in the specified cambered drive arrangement
- Construction: Steel drive flange with internal ball-spline components
Fitment & Compatibility
Match the 24-spline rear drive shaft and five-bolt Wide 5 hub interface. This cambered drive flange requires the specified axle alignment and matching cover.
Wilwood component specifications
PMB Performance brings over 20 years of experience to brake-component selection. Provide the actual hardware specification when the brake system has been modified.
