Product details
A six-lug wheel flange distinguishes this Chevrolet C10/C15 front hat hub. The separate rotor hat, spindle bearings and three retention screws belong to the documented conversion; wheel pattern alone cannot establish fitment. Founded by Bill Wood in 1977, Wilwood Engineering designs and manufactures disc brake systems from Camarillo, California. Its calipers, brake rotors, master cylinders, valves, fittings and brake lines serve motorsport, street-performance and specialized applications. Individual components must be selected for the complete brake system.
Technical Details
- Manufacturer part number: 270-15790
- Rotor mounting arrangement: Hat
- Product-page drawing references (inches): D = 2.561; H = 2.180; M = 3.570; N = 1.710; P = 3.300; Q = 0.120. Use the manufacturer drawing for the reference faces.
- Manufacturer bearing / race references: Inner Bearing: 370-2609; Outer Bearing: 370-9542; Inner Hub Bearing - Race: 370-2571; Outer Hub Bearing - Race: 370-9245. References identify compatible service parts and do not mean all bearings are included.
- Package: One hub; the compatible rotor, rotor adapter or hat and its attachment hardware are selected for the complete conversion
- Hat retention: Three 1/4-20 holes; Wilwood lists bolt kit 230-7032
- Hub closure and races: Manufacturer describes included bearing races and screw-on aluminum cap; confirm the supplied assembly and obtain the compatible bearings separately
- Component: Hub - Hat Mount
- Position in the specified assembly: Front
- Material: Aluminum
- Finish: Bare
- Wheel mounting pattern(s): 6 x 5.50 inches; separate from rotor or drive-flange attachment
- Wheel-stud thread: 1/2-20
Fitment & Compatibility
Select the replacement around the existing spindle, bearing and rotor assembly. The vehicle application describes a brake conversion and does not establish an original-equipment hub replacement.
Wilwood component specifications · Manufacturer reference DS719
With more than 20 years of parts and fitment experience, PMB Performance can help compare the existing brake assembly with the required component.
