Product details
This Cadillac front hub is single drilled on a five-on-five wheel circle. It supports a separate rotor plate and requires the specified press-on bearing cap in addition to the correct spindle bearings. Wilwood Engineering’s work covers the design and manufacture of disc brake systems for motorsport, street-performance and specialized applications. Bill Wood founded the company in 1977 in a business now based in Camarillo, California. Its calipers, master cylinders, brake rotors, brake lines, valves and fittings must be selected around the complete system.
Technical Details
- Manufacturer part number: 270-12788
- Material: Aluminum
- Finish: Bare
- Wheel mounting pattern(s): 5 x 5.00 inches; separate from rotor or drive-flange attachment
- Wheel-stud thread: 1/2-20
- Rotor mounting arrangement: Adapter
- Rotor interface: 5 x 3.88; this is not the wheel bolt circle
- Compatible rotor-adapter output interface(s): 6 x 6.25, 8 x 7.00; match the actual adapter and rotor
- Product-page drawing references (inches): A = 1.820; D = 2.624; H = 1.394; M = 3.700; N = 2.320; P = 3.040; Q = 0.250. Use the manufacturer drawing for the reference faces.
- Manufacturer bearing / race references: Inner Bearing: 370-0884; Outer Bearing: 370-0933; Inner Hub Bearing - Race: 370-0883; Outer Hub Bearing - Race: 370-0881. References identify compatible service parts and do not mean all bearings are included.
- Related assembly part reference(s): 300-3307; 300-3099; check the kit contents and obtain any separately required parts
- Package: One hub; the compatible rotor, rotor adapter or hat and its attachment hardware are selected for the complete conversion
- Bearing cap: Press-on steel cap 270-12403 available separately
- Component: Hub - Vented Rotor Offset
- Position in the specified assembly: Front
Fitment & Compatibility
Use the exact conversion instructions to compare the spindle and hub dimensions. Confirm the bearing seats, rotor mounting arrangement and wheel-stud engagement before assembling the replacement.
Wilwood component specifications · Manufacturer reference DS719
Ask PMB Performance for help comparing the installation requirements. We have more than 20 years of experience working with brake parts and fitment.
