Product details
A6 and A34 bearing references identify this hat-mount Camaro hub's spindle arrangement. Use it with the correct separate rotor hat and confirm wheel-flange position before choosing a replacement. Wilwood Engineering’s work covers the design and manufacture of disc brake systems for motorsport, street-performance and specialized applications. Bill Wood founded the company in 1977 in a business now based in Camarillo, California. Its calipers, master cylinders, brake rotors, brake lines, valves and fittings must be selected around the complete system.
Technical Details
- Manufacturer part number: 270-10494
- Manufacturer bearing / race references: Inner Bearing: 370-0879; Outer Bearing: 370-0933; Inner Hub Bearing - Race: 370-0878; Outer Hub Bearing - Race: 370-0881. References identify compatible service parts and do not mean all bearings are included.
- Package: One hub; the compatible rotor, rotor adapter or hat and its attachment hardware are selected for the complete conversion
- Hat retention: Three 1/4-20 holes; Wilwood lists bolt kit 230-7032
- Hub closure and races: Manufacturer describes included bearing races and screw-on aluminum cap; confirm the supplied assembly and obtain the compatible bearings separately
- Component: Hub - Hat Mount
- Position in the specified assembly: Front
- Material: Aluminum
- Finish: Bare
- Wheel mounting pattern(s): 5 x 4.50, 5 x 4.75 inches; separate from rotor or drive-flange attachment
- Wheel-stud thread: 1/2-20
- Rotor mounting arrangement: Hat
- Product-page drawing references (inches): D = 2.495; H = 1.810; M = 3.150; N = 1.630; P = 2.850; Q = 0.100. Use the manufacturer drawing for the reference faces.
Fitment & Compatibility
Compare the spindle journals, bearing references and hub mounting faces with the complete brake assembly. A shared wheel bolt pattern alone does not establish hub interchangeability.
Wilwood component specifications · Manufacturer reference DS719
PMB Performance has over 20 years of brake-parts experience. Send the installed component details if you need help checking this replacement.
