Product details
The seven-tenths-inch version of Wilwood's compact integral master combines the cylinder and a small fluid reservoir in one aluminum body. A screw-on filler cap and single inverted-flare outlet support the specified clutch and smaller hydraulic-master requirements. Founded by Bill Wood in 1977, Wilwood Engineering is based in Camarillo, California. The company designs and builds disc brake systems, with calipers, master cylinders, rotors, brake lines, fittings and valves serving street-performance, motorsport and specialized applications. Selecting an individual part requires checking how it works with the rest of the braking assembly.
Technical Details
- Manufacturer part number: 260-6579
- Material: Aluminum
- Cylinder bore: .70
- Pressure circuits: 1
- Stroke Length: 1.40 in
- Listed displacement per stroke: 0.53 cu in
- Reservoir Type: Integral
- Fluid capacity: 1.4 oz
- Flange-to-end length: 3.91"
- Mounting centers: 2.25"
- Pushrod dimensions: 4.00" x 5/16-24
- Finish: Bare
- Fluid reservoir: Integral 1.4 oz chamber
- Pressure outlet: 3/8-24 inverted flare
- Outlet connection: 3/8-24 IF Female
Fitment & Compatibility
Check reservoir reserve, the 0.53-cubic-inch specified displacement and the complete piston stroke against the intended circuit. The mounting centers are 2.25 inches and the four-inch rod is threaded 5/16-24. Provide suitable flare-seat plumbing and enough cap clearance for routine fluid inspection.
