Wilwood 1-1/8-inch Combination Remote Master Cylinder Internal Rebuild Kit

A one-and-one-eighth-inch piston distinguishes this larger-bore Combination Remote rebuild kit. It renews the hydraulic sealing assembly and associated spring, boot and retaining parts without supplying a cylinder body or reservoir. Wilwood Engineering's design and manufacturing work covers disc brake systems for specialized applications, street performance and motorsport. Founded by Bill Wood in 1977, the company operates from Camarillo, California. Its component range includes master cylinders, fittings, brake lines, rotors, valves and calipers, each requiring selection in the context of the complete brake system.

Technical Details

• Manufacturer part number: 260-3884
• Component: Cylinder rebuild/service kit; replacement housing not included
• Service bore: 1-1/8"
• Kit contents: Piston/seals, spring, thin cup washer, retaining ring, boot and two O-rings
• Reused components: Existing pushrod and retaining washer item 3 are not included and must be reused

Fitment & Compatibility

Use for the specified 260-3380 master and verify the bore before disassembly. Reuse only the correct serviceable pushrod and washer identified in DS-241. The family and bore must both match; a large-bore Compact Remote or tandem master requires its own service arrangement.

Manufacturer Documents

• Wilwood product specifications
• Wilwood DS241 instructions and specifications
• Wilwood FL162 instructions and specifications

The component must suit the completed installation. PMB Performance draws on over 20 years of experience to help you check the part identification, mating connections and required operating dimensions.
