Product details
A small integral reservoir and five-eighths-inch bore make this compact aluminum master suitable for the specified clutch and smaller hydraulic requirements. The bare body carries a screw-on cap, a threaded pedal rod and one pressure outlet. Based in Camarillo, California, Wilwood Engineering has designed and manufactured disc brake systems since Bill Wood founded the company in 1977. Its fittings, valves, calipers, brake lines, master cylinders and rotors are used across motorsport, street-performance and specialized applications. Matching a component means checking both its own specification and the braking assembly around it.
Technical Details
- Manufacturer part number: 260-2636
- Material: Aluminum
- Cylinder bore: 5/8"
- Pressure circuits: 1
- Stroke Length: 1.40 in
- Listed displacement per stroke: 0.43 cu in
- Reservoir Type: Integral
- Fluid capacity: 1.4 oz
- Flange-to-end length: 3.91"
- Mounting centers: 2.25"
- Pushrod dimensions: 4.00" x 5/16-24
- Finish: Bare
- Fluid reservoir: Integral 1.4 oz chamber
- Pressure outlet: 3/8-24 inverted flare
- Outlet connection: 3/8-24 IF Female
Fitment & Compatibility
Check the connected slave or brake circuit's volume requirement against the 1.4-ounce fluid supply. The flange uses 2.25-inch centers, the rod has a 5/16-24 thread and the outlet takes a 3/8-24 female inverted-flare connection. Allow the complete 1.40-inch stroke and preserve free return.
Manufacturer Documents
PMB Performance has more than 20 years of experience matching brake components. Share the actual mounting, linkage and hydraulic arrangement when requesting fitment assistance.
