Product details
A left-hand bracket places the included adjustable combination valve beside a compatible high-volume tandem master cylinder. Formed stainless lines and the mounting hardware connect and support the valve; the master cylinder itself is purchased separately. Wilwood Engineering's design and manufacturing work covers disc brake systems for specialized applications, street performance and motorsport. Founded by Bill Wood in 1977, the company operates from Camarillo, California. Its component range includes master cylinders, fittings, brake lines, rotors, valves and calipers, each requiring selection in the context of the complete brake system.
Technical Details
- Manufacturer part number: 260-13190
- Material: Aluminum / Steel
- Primary Outlet Thread Size: 3/8-24 IF
- Finish: Clear Anodize / Black E-coat
- Kit contents: Combination proportioning valve, mounting bracket, formed stainless lines and fastening hardware; master cylinder is not included
- Bracket side: Left
- Valve functions: Adjustable rear pressure, hydraulic brake-light switch and isolated front/rear circuits
- Fluid inlet: 3/8-24 IF
- Outlet connection: 3/8-24 IF
Fitment & Compatibility
Use with the specified high-volume tandem families, including 260-8555, 260-8556, 260-9439, 260-12900 and 260-13375. Check clearance on the master's left side and retain correct primary and secondary circuit plumbing. The bracket instructions also cover bracket-only packages, but this complete kit includes the combination valve.
Manufacturer Documents
- Wilwood product specifications
- Wilwood DS985 instructions and specifications
- Wilwood FL383 instructions and specifications
- Wilwood FL162 instructions and specifications
The component must suit the completed installation. PMB Performance draws on over 20 years of experience to help you check the part identification, mating connections and required operating dimensions.
