Product details
A left-side handlebar clamp and long aluminum lever identify this integrated brake control. The five-eighths-inch master cylinder draws from its translucent reservoir and provides the specified three-position hydraulic brake lock for the intended equipment application. Wilwood Engineering began in 1977 under founder Bill Wood and is based in Camarillo, California. The company designs and builds disc brake systems for motorsport, street-performance and specialized applications, with a range extending through calipers, rotors, valves, brake lines, fittings and master cylinders. Individual parts must be compatible with the system in which they operate.
Technical Details
- Manufacturer part number: 260-11219
- Material: Aluminum / Plastic
- Cylinder bore: 5/8"
- Pressure circuits: 1
- Stroke Length: 0.45 in
- Listed displacement per stroke: 0.12 cu in
- Reservoir Type: Integral
- Overall Length: 9.85"
- Mounting centers: 7/8" Dia.
- Finish: Black E-coat
- Bar diameter: 7/8 inch
- Lever: Long lever, aluminum
- Lock: Three-position hydraulic holding mechanism
- Side: Left hand
- Connection: M10 × 1.0 banjo pressure port; accepts a separate 1/4-32 threaded brake-light switch
Fitment & Compatibility
Confirm bar diameter, clearance throughout lever travel and the required left-hand layout. Use an M10 x 1 banjo fitting at the pressure port; a compatible brake-light switch uses the separate 1/4-32 threaded location. Selection still depends on the connected brake system's fluid demand.
