Wilwood Single Billet Fluid Reservoir Bracket, Bare Finish, 2.75-inch Mounting Centers

For a remote installation needing only one fluid supply, this bare billet bracket holds a single round Wilwood reservoir. Its compact footprint uses 2.75-inch mounting centers rather than the wider spacing of the dual bracket. From calipers and rotors to master cylinders, valves, brake lines and fittings, Wilwood Engineering's range covers disc brake systems and service components. Bill Wood founded the company in 1977; it is based in Camarillo, California and designs and manufactures for street-performance, specialized and motorsport applications. All component choices need to account for the complete system.

Technical Details

• Manufacturer part number: 250-16871
• Material: Aluminum
• Mounting centers: 2.75 inches
• Finish: Bare
• Component: Billet reservoir mounting bracket with fastening screws
• Reservoir positions: 1
• Reservoir body diameter: Nominal 2.45 inches
• Supplied: Bracket and screws only; reservoirs and hoses are separate

Fitment & Compatibility

The clamp is sized for nominal 2.45-inch Wilwood Billet and Lightweight Billet reservoirs. Check the 3.25-inch overall width and accessible cap location before positioning it; the reservoir and fluid hose are separate components.

Manufacturer Documents

• Wilwood product specifications
• Wilwood DS1448 instructions and specifications
• Wilwood FL162 instructions and specifications

For help choosing the correct service or conversion component, contact PMB Performance with the existing brake-system details. Our team has over 20 years of experience working through parts and fitment requirements.
