Product details
The XD55 adapter connection uses five one-inch countersunk bolts in this kit. Grade 8 alloy steel, 3/8-16 threads and an internal-hex drive distinguish these fasteners from the smaller Starlite 55 Torx set. Wilwood Engineering designs and manufactures disc brake systems for motorsport, street-performance and specialized applications from its base in Camarillo, California. Bill Wood founded the company in 1977. Its calipers, rotors, master cylinders, valves, fittings and brake lines are individual components that must be selected in the context of the complete brake system.
Technical Details
- Manufacturer part number: 230-17479
- Component quantity: 5 bolts
- Material: Alloy Steel
- Grade: Grade 8
- Head form: Flat Head
- Drive: Hex Drive
- Listed fastener length: 1.000 in
- Thread: 3/8-16
- Safety-wire drilling: No
- Finish: Black Oxide
Fitment & Compatibility
Use with the specified Starlite 55XD lug-drive rotor adapter. Confirm the countersink profile, thread depth and mounting instructions before tightening the assembly.
Wilwood product specifications
PMB Performance's 20+ years of experience can help with the details that determine fit. Supply the brake assembly number and the dimensions of the parts being replaced.
