Product details
This DLS mounting kit is distinguished by its one-inch bolt length and lock-wire-drilled hex heads. Four Grade 8 bolts are supplied with washers and shims for the specified 3/8-24 caliper connection. Bill Wood founded Wilwood Engineering in 1977. From Camarillo, California, the company designs and manufactures disc brake systems, including rotors, calipers, valves, master cylinders, brake lines and fittings. These products serve specialized, motorsport and street-performance applications, where the requirements of the complete brake system determine component choice.
Technical Details
- Manufacturer part number: 230-14337
- Head form: Hex Head
- Drive: Hex
- Listed fastener length: 1.000 in
- Thread: 3/8-24
- Washer type: Flat
- Safety-wire drilling: Yes
- Finish: Dacromet
- Component quantity: 4 bolts
- Material: Alloy Steel
- Grade: Grade 8
Fitment & Compatibility
Verify the bracket calls for one-inch fasteners rather than the longer Dynalite mounting set. Establish caliper alignment and apply the specified torque and lock-wire procedure.
Wilwood product specifications
PMB Performance's 20+ years of experience can help with the details that determine fit. Supply the brake assembly number and the dimensions of the parts being replaced.
