Product details
The integrated bubble-flare socket on this Wilwood hose removes the need for a separate chassis adapter at that interface. Its 22-inch length ends in a straight female -3 connection for the selected brake fitting. Disc brake system design and manufacturing are Wilwood Engineering’s focus. Bill Wood founded the Camarillo, California company in 1977; its range spans brake rotors, master cylinders, calipers, fittings, valves and brake lines for motorsport, specialized and street-performance applications. The choice of individual components depends on the complete brake system.
Technical Details
- Manufacturer part number: 220-9684
- Component: Individual braided brake hose
- Hose length (inches): 22.00
- Line or fitting size: -3
- Hose inlet connection: M10 bubble flare Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Hose quantity: 1
- Listed weight: 0.500 lb
Fitment & Compatibility
Match the actual M10 x 1 seat and the available routing distance before fitting this single universal line. Do not substitute an inverted-flare socket or overlook the support required by the longer flexible section.
Manufacturer Documents
PMB Performance draws on over 20 years of brake and parts experience. Clear photographs of the connections and the installed brake package are useful when confirming this component.
