Product details
Wilwood supplies alternate imperial chassis fittings and angled mounting brackets with this classic Mustang hose set. The 18-inch lines use 45-degree caliper adapters to follow the specified front conversion route. Since its founding by Bill Wood in 1977, Wilwood Engineering has developed a range serving motorsport, street-performance and specialized brake applications. Based in Camarillo, California, it designs and manufactures disc brake systems, calipers, brake rotors, master cylinders, valves, fittings and brake lines. Each component should be selected for compatibility with the complete braking system.
Technical Details
- Manufacturer part number: 220-9195
- Component: Brake flexline and fitting kit
- Hose length (inches): 18.00
- Line or fitting size: -3
- Chassis adapter connection: -3 to 3/8-24 inverted flare or 7/16-24 inverted flare
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Caliper adapter angle: 45 Degree
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-6412
- Chassis adapter reference: 220-13124 / 220-6457
- Chassis retaining clip reference: 300-15780
- Line support reference: 250-9349 / 250-9350
- Hose quantity: 2
- Listed weight: 1.000 lb
Fitment & Compatibility
Wilwood flyer FL173 lists this hose kit with the 1968–1969 and 1970–1973 Mustang front brake packages. Confirm the exact spindle and brake kit, then select the 3/8-24 or 7/16-24 inverted-flare connection that matches the car.
Manufacturer Documents
- Wilwood product specifications
- Wilwood flexline fitting guide
- Wilwood application and installation reference
- Wilwood application and installation reference
PMB Performance has over 20 years of experience with brake components and fitment. Send the vehicle details, installed brake kit and connection measurements if you need help choosing the correct plumbing.
