Product details
The GTO rear conversion uses this short Wilwood hose pair with separate metric chassis adapters. Its 10-inch flexlines connect through right-angle fittings at the NPT caliper ports. Since its founding by Bill Wood in 1977, Wilwood Engineering has focused on disc brake system design and manufacturing. Based in Camarillo, California, it offers calipers, rotors, brake lines, master cylinders, fittings and valves for motorsport, street-performance and specialized installations. Choose components to satisfy the requirements of the entire braking system.
Technical Details
- Manufacturer part number: 220-8756
- Component: Brake flexline and fitting kit
- Hose length (inches): 10.00
- Line or fitting size: -3
- Chassis adapter connection: -3 to M10 x 1 bubble flare
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Caliper adapter angle: 90 Degree
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-13125
- Chassis adapter reference: 220-6890
- Hose quantity: 2
- Listed weight: 0.800 lb
Fitment & Compatibility
Verify the 2005–2006 Pontiac GTO rear brake kit and M10 x 1 bubble-flare hard-line seats. Check the route at full suspension movement; the longer front set includes different mounting hardware and is not an automatic alternative.
Manufacturer Documents
PMB Performance has over 20 years of experience with brake components and fitment. Send the vehicle details, installed brake kit and connection measurements if you need help choosing the correct plumbing.
