Product details
The rear C4 replacement kit uses shorter 13-inch hoses with 45-degree banjo blocks. Wilwood includes the bolt-and-washer hardware with the two hoses for the specified original-caliper arrangement. Wilwood Engineering’s work covers the design and manufacture of disc brake systems for motorsport, street-performance and specialized applications. Bill Wood founded the company in 1977 in a business now based in Camarillo, California. Its calipers, master cylinders, brake rotors, brake lines, valves and fittings must be selected around the complete system.
Technical Details
- Manufacturer part number: 220-8517
- Component: Brake flexline and fitting kit
- Hose length (inches): 13.00
- Line or fitting size: -3
- Hose inlet connection: M10 bubble flare Female
- Hose inlet angle: Straight
- Hose outlet connection: M10 Banjo
- Hose outlet angle: 45 Degree
- Chassis retaining clip reference: 300-15780
- Hose quantity: 2
- Listed weight: 0.800 lb
Fitment & Compatibility
Verify the 1988–1996 Chevrolet Corvette C4 rear caliper interface and metric bubble-flare chassis seat. Do not exchange this kit with the longer front hose set or an NPT conversion package without matching the complete installation.
Manufacturer Documents
PMB Performance can help compare the fitting arrangement with your brake system, drawing on over 20 years of experience. Include the vehicle details and clear views of the mating hardware.
