Product details
These C5 front hoses adapt the chassis plumbing to Wilwood conversion calipers through separate NPT elbows. The 17-inch lines incorporate metric bubble-flare sockets and straight female -3 outlets. A complete brake system depends on compatible component selection. Wilwood Engineering designs and manufactures disc brake systems along with calipers, brake rotors, master cylinders, valves, fittings and brake lines for motorsport, street-performance and specialized use. Bill Wood founded Wilwood in 1977; the company is based in Camarillo, California.
Technical Details
- Manufacturer part number: 220-8176
- Component: Brake flexline and fitting kit
- Hose length (inches): 17.00
- Line or fitting size: -3
- Hose inlet connection: M10 bubble flare Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Caliper adapter angle: 90 Degree
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-13125
- Chassis retaining clip reference: 300-15780
- Hose quantity: 2
- Listed weight: 0.800 lb
Fitment & Compatibility
Check the exact 1997–2004 Chevrolet Corvette C5 front conversion, including its hose routing and caliper inlet. The original-caliper banjo hose kit is a different assembly and should not be selected solely because it fits the same Corvette generation.
Manufacturer Documents
PMB Performance has over 20 years of experience with brake components and fitment. Send the vehicle details, installed brake kit and connection measurements if you need help choosing the correct plumbing.
