Product details
This Bronco front hose kit uses 22-inch straight-ended lines with coarse-pitch M10 x 1.5 chassis adapters. The caliper connection is made through a separate 90-degree 1/8-27 NPT elbow. The manufacturer, Wilwood Engineering, was established by Bill Wood in 1977 and is based in Camarillo, California. It designs and builds disc brake systems with a range covering calipers, brake rotors, master cylinders, valves, fittings and brake lines. Motorsport, street-performance and specialized applications require components selected for the complete braking system.
Technical Details
- Manufacturer part number: 220-17599
- Component: Brake flexline and fitting kit
- Hose length (inches): 22.00
- Line or fitting size: -3
- Chassis adapter connection: -3 to M10 x 1.5 inverted flare
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Caliper adapter angle: 90 Degree
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-13125
- Chassis adapter reference: 220-13923
- Chassis retaining clip reference: 300-15780
- Hose quantity: 2
- Listed weight: 0.900 lb
Fitment & Compatibility
The product identity specifies the Ford Bronco front application from 2021 onward. Confirm the actual Wilwood conversion and full suspension travel; the Bronco Sport and other Ford front brake systems are not established applications for this kit.
Manufacturer Documents
Use PMB Performance's 20-plus years of experience when checking uncertain fitment. Identify the actual hose ends, port seats and brake package as well as the vehicle before ordering.
