Product details
For the Ram 1500 rear 15-inch rotor conversion, Wilwood pairs an angled hose end with a separate right-angle caliper adapter. The 16-inch flexlines connect to imperial inverted-flare chassis fittings, a distinction from several metric-thread front kits. For Wilwood Engineering, component selection forms part of matching a complete brake system to its application. Founded in 1977 by Bill Wood and based in Camarillo, California, the company designs and manufactures disc brake systems and a range of calipers, brake rotors, master cylinders, valves, fittings and brake lines for motorsport, street-performance and specialized applications.
Technical Details
- Manufacturer part number: 220-16025
- Component: Brake flexline and fitting kit
- Hose length (inches): 16.00
- Line or fitting size: -3
- Chassis adapter connection: -3 to 3/8-24 inverted flare
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: 90 Degree
- Caliper adapter angle: 90 Degree
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-13125
- Chassis adapter reference: 220-13124
- Chassis retaining clip reference: 300-15780
- Hose quantity: 2
- Listed weight: 0.980 lb
Fitment & Compatibility
The application note covers 2013–2017 Ram 1500 rear conversions with 15-inch rotors. Check the exact rear brake package and 3/8-24 chassis seat rather than assuming the front and rear hard-line connections are identical.
Manufacturer Documents
Use PMB Performance's 20-plus years of experience when checking uncertain fitment. Identify the actual hose ends, port seats and brake package as well as the vehicle before ordering.
