Wilwood Front 20-Inch Brake Hose Kit for Ford F-150 Raptor (2010–2014), Angled Ends

Wilwood specifies this front hose set for the 2010–2014 Ford F-150 Raptor brake conversion. Each 20-inch hose has an angled end, with M10 x 1 inverted-flare chassis adapters and 90-degree NPT caliper fittings supplied separately. Since its founding by Bill Wood in 1977, Wilwood Engineering has focused on disc brake system design and manufacturing. Based in Camarillo, California, it offers calipers, rotors, brake lines, master cylinders, fittings and valves for motorsport, street-performance and specialized installations. Choose components to satisfy the requirements of the entire braking system.

Technical Details

• Manufacturer part number: 220-15837
• Component: Brake flexline and fitting kit
• Hose length (inches): 20.00
• Line or fitting size: -3
• Chassis adapter connection: -3 to M10 x 1 inverted flare
• Hose inlet connection: -3 Female
• Hose inlet angle: Straight
• Hose outlet connection: -3 Female
• Hose outlet angle: 90 Degree
• Caliper adapter angle: 90 Degree
• Caliper connection: 1/8-27 NPT
• Caliper adapter reference: 220-13125
• Chassis adapter reference: 220-6413
• Chassis retaining clip reference: 300-15780
• Hose quantity: 2
• Listed weight: 0.880 lb

Fitment & Compatibility

DS-1526 identifies these hoses with the front Aero6-DM Raptor kit and shows the angled hose end at the chassis fitting. Match the installed front kit and routing; the Raptor rear hose package is a different part.

Manufacturer Documents

• Wilwood product specifications
• Wilwood flexline fitting guide
• Wilwood application and installation reference

Use PMB Performance's 20-plus years of experience when checking uncertain fitment. Identify the actual hose ends, port seats and brake package as well as the vehicle before ordering.
