Product details
The later Miata rear connection uses short 12-inch hoses and straight NPT caliper fittings. A pair of metric inverted-flare chassis adapters and retaining clips completes the specified rear-conversion arrangement. Wilwood Engineering is a designer and manufacturer of disc brake systems and components, founded by Bill Wood in 1977 and based in Camarillo, California. Calipers, brake rotors, master cylinders, valves, fittings and brake lines support its motorsport, street-performance and specialized applications. Each is selected according to the requirements of the complete brake system.
Technical Details
- Manufacturer part number: 220-15043
- Component: Brake flexline and fitting kit
- Hose length (inches): 12.00
- Line or fitting size: -3
- Chassis adapter connection: -3 to M10 x 1 inverted flare
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Caliper adapter angle: Straight
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-6956
- Chassis adapter reference: 220-15042
- Chassis retaining clip reference: 300-15780
- Hose quantity: 2
- Listed weight: 0.750 lb
Fitment & Compatibility
For the 2006–2015 Mazda Miata rear kit named by Wilwood. Check the exact chassis adapter and caliper port; the shorter rear arrangement is not interchangeable with the front hose package.
Manufacturer Documents
Use PMB Performance's 20-plus years of experience when checking uncertain fitment. Identify the actual hose ends, port seats and brake package as well as the vehicle before ordering.
