Product details
Angled L-brackets distinguish this 20-inch metric line package from otherwise similar hose kits. The hoses use straight female -3 ends, with M10 x 1 bubble-flare chassis adapters and separate 90-degree NPT caliper fittings. Wilwood Engineering's range covers calipers, brake rotors, master cylinders, valves, fittings and brake lines, selected to meet the needs of a complete brake system. The company was founded by Bill Wood in 1977 and is based in Camarillo, California, designing and manufacturing disc brake systems for motorsport, street-performance and specialized applications.
Technical Details
- Manufacturer part number: 220-14177
- Component: Brake flexline and fitting kit
- Hose length (inches): 20.00
- Line or fitting size: -3
- Chassis adapter connection: -3 to M10 x 1 bubble flare
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Caliper adapter angle: 90 Degree
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-13125
- Chassis adapter reference: 220-6890
- Chassis retaining clip reference: 300-15780
- Line support reference: 250-9439 / 250-9340
- Hose quantity: 2
Fitment & Compatibility
Confirm the bracket geometry and its attachment points before selecting the kit. Thread and hose length alone will not establish a secure route where the mounting arrangement differs.
