Product details
The short metric mounting package retains straight hose and caliper connections throughout the hydraulic route. Wilwood lists M10 x 1 and M10 x 1.5 chassis-adapter options for the two 14-inch lines and their bracket arrangement. Camarillo, California is home to Wilwood Engineering, founded by Bill Wood in 1977. Wilwood designs and manufactures disc brake systems and components for motorsport, street-performance and specialized applications, including calipers, brake rotors, master cylinders, valves, fittings and brake lines. Those components need to be selected together around the complete brake system's requirements.
Technical Details
- Manufacturer part number: 220-14166
- Component: Brake flexline and fitting kit
- Hose length (inches): 14.00
- Line or fitting size: -3
- Chassis adapter connection: M10 x 1 inverted flare or M10 x 1.5 inverted flare
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Caliper adapter angle: Straight
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-6956
- Chassis adapter reference: 220-6413 / 220-13923
- Chassis retaining clip reference: 300-15780
- Line support reference: 250-12864 / 250-12865
- Hose quantity: 2
- Listed weight: 0.950 lb
Fitment & Compatibility
Match the adapter to the installed hard-line thread and inverted-flare seat. The same 10 mm diameter does not make different thread pitches interchangeable, and the brackets must align with the actual chassis mounts.
