Product details
Straight caliper adapters maintain an axial hose approach in this 14-inch mounting package. The two braided hoses connect to imperial inverted-flare chassis adapters, and the supplied brackets establish the chassis-side retention points. For Wilwood Engineering, component selection forms part of matching a complete brake system to its application. Founded in 1977 by Bill Wood and based in Camarillo, California, the company designs and manufactures disc brake systems and a range of calipers, brake rotors, master cylinders, valves, fittings and brake lines for motorsport, street-performance and specialized applications.
Technical Details
- Manufacturer part number: 220-14165
- Component: Brake flexline and fitting kit
- Hose length (inches): 14.00
- Line or fitting size: -3
- Chassis adapter connection: -3 to 3/8-24 inverted flare
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Caliper adapter angle: Straight
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-6956
- Chassis adapter reference: 220-13124
- Chassis retaining clip reference: 300-15780
- Line support reference: 250-12864 / 250-12865
- Hose quantity: 2
- Listed weight: 0.950 lb
Fitment & Compatibility
Use where the caliper ports and mounting layout permit a straight connection. Confirm the 3/8-24 flare seat and bracket geometry before treating this arrangement as interchangeable with a kit using caliper elbows.
Manufacturer Documents
If the brake system has been modified, contact PMB Performance with the installed component references and routing dimensions. We have more than 20 years of experience helping match brake parts to their applications.
