Product details
This rear JK line package joins imperial inverted-flare chassis plumbing to 90-degree NPT caliper adapters. Wilwood specifies two 20-inch hoses and the rear bracket arrangement for the Jeep conversion. Bill Wood founded Wilwood Engineering in 1977, and the manufacturer is based in Camarillo, California. Wilwood designs and manufactures disc brake systems alongside calipers, master cylinders, rotors, fittings, brake lines and valves. The motorsport, street-performance and specialized ranges depend on components selected to work within a complete braking system.
Technical Details
- Manufacturer part number: 220-13968
- Component: Brake flexline and fitting kit
- Hose length (inches): 20.00
- Line or fitting size: -3
- Chassis adapter connection: -3 to 3/8-24 inverted flare
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Caliper adapter angle: 90 Degree
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-13125
- Chassis adapter reference: 220-13124
- Line support reference: 250-9140 / 250-9141
- Hose quantity: 2
- Listed weight: 0.950 lb
Fitment & Compatibility
Use the specified Wrangler JK rear installation identified from 2007 onward. The JK designation is material: do not carry this hose application into JL or JT generations without their own kit instructions.
Manufacturer Documents
PMB Performance draws on over 20 years of brake and parts experience. Clear photographs of the connections and the installed brake package are useful when confirming this component.
