Product details
The later Mustang rear arrangement calls for a longer 22-inch line pair and its own mounting brackets. M10 x 1.5 inverted-flare chassis adapters connect the hoses to 45-degree NPT caliper fittings. Established in 1977 by Bill Wood, Camarillo, California-based Wilwood Engineering designs and manufactures disc brake systems. Its master cylinders, calipers, brake rotors, lines, fittings and valves support motorsport, street-performance and specialized applications, with each component selected for its role in the complete brake system.
Technical Details
- Manufacturer part number: 220-13913
- Component: Brake flexline and fitting kit
- Hose length (inches): 22.00
- Line or fitting size: -3
- Chassis adapter connection: -3 to M10 x 1.5 inverted flare
- Hose inlet connection: -3 Female
- Hose outlet connection: -3 Female
- Caliper adapter angle: 45 Degree
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-6412
- Chassis adapter reference: 220-13923
- Chassis retaining clip reference: 300-15780
- Line support reference: 250-9140 / 250-9141
- Hose quantity: 2
Fitment & Compatibility
Confirm the rear Wilwood conversion within the manufacturer's 2015-onward Mustang application. The photograph shows angled hose ends while the fitting fields say straight; verify the delivered hose geometry as well as the bracket placement.
Manufacturer Documents
With more than 20 years of experience, PMB Performance can assist with brake-component selection. Provide the vehicle and installed brake details so the connection and mounting requirements can be checked together.
