Product details
The short eight-inch rear line arrangement differs substantially from the E90 front hose package. Straight NPT caliper fittings and separate metric bubble-flare chassis adapters connect to the two straight-ended braided hoses. Wilwood Engineering’s work covers the design and manufacture of disc brake systems for motorsport, street-performance and specialized applications. Bill Wood founded the company in 1977 in a business now based in Camarillo, California. Its calipers, master cylinders, brake rotors, brake lines, valves and fittings must be selected around the complete system.
Technical Details
- Manufacturer part number: 220-13647
- Component: Brake flexline and fitting kit
- Hose length (inches): 8.00
- Line or fitting size: -3
- Chassis adapter connection: -3 to M10 x 1 bubble flare
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Caliper adapter angle: Straight
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-6956
- Chassis adapter reference: 220-6890
- Hose quantity: 2
- Listed weight: 0.700 lb
Fitment & Compatibility
Select for the specified 2007–2011 BMW E90 3 Series rear conversion. Confirm that the installation uses this short connection at the designated points, rather than treating it as a replacement for every flexible section of the rear circuit.
Manufacturer Documents
For a fitment check, give PMB Performance the vehicle year, brake configuration and details of both mating connections. Our team brings more than 20 years of parts and brake-system experience to the comparison.
