Product details
The 12-inch line is the longest of the four listed billet-reservoir feed arrangements in this group. One straight-ended -3 hose and the compact master-cylinder inlet adapter provide the connection, with an O-ring for the specified inlet seal. Bill Wood founded Wilwood Engineering in 1977. From its base in Camarillo, California, Wilwood designs and manufactures disc brake systems and components for motorsport, street-performance and specialized use, including calipers, brake rotors, master cylinders, valves, fittings and brake lines. Compatibility with the complete brake system governs selection of the individual components.
Technical Details
- Manufacturer part number: 220-13005
- Component: Reservoir-to-master cylinder feed hose kit
- Hose length (inches): 12.00
- Line or fitting size: -3
- Connection specification: 11/16-20 to -3
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Master cylinder adapter angle: Straight
- Inlet adapter: 11/16-20 to male -3 with O-ring
- Master cylinder adapter reference: 220-13130
- Package quantity: 1
Fitment & Compatibility
Use only with the Wilwood reservoir and compact remote master-cylinder connections identified for this feed kit. Choose length from the actual mounting route and verify the 11/16-20 master-cylinder port.
