Product details
A single 10-inch braided feed hose links the compatible billet reservoir arrangement to a compact remote master cylinder. The included 11/16-20 inlet fitting converts the master-cylinder connection to -3 and uses an O-ring at its sealing shoulder. The Wilwood range brings together calipers, brake rotors, master cylinders, valves, fittings and brake lines for complete-system component selection. Wilwood Engineering was founded by Bill Wood in 1977, is based in Camarillo, California, and designs and manufactures disc brake systems and components for motorsport, street-performance and specialized applications.
Technical Details
- Manufacturer part number: 220-13004
- Component: Reservoir-to-master cylinder feed hose kit
- Hose length (inches): 10.00
- Line or fitting size: -3
- Connection specification: 11/16-20 to -3
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Master cylinder adapter angle: Straight
- Inlet adapter: 11/16-20 to male -3 with O-ring
- Master cylinder adapter reference: 220-13130
- Package quantity: 1
Fitment & Compatibility
Measure the reservoir-to-master route before selecting this intermediate length. Confirm the reservoir outlet adapter separately and avoid applying the kit's master-cylinder fitting to a differently threaded inlet.
Manufacturer Documents
Use PMB Performance's 20-plus years of experience when checking uncertain fitment. Identify the actual hose ends, port seats and brake package as well as the vehicle before ordering.
