Product details
Wilwood's current application and kit notes identify a 1940–1952 Oldsmobile front-conversion package. The listed hydraulic layout uses 16-inch lines, 7/16-24 inverted-flare chassis adapters and right-angle NPT caliper fittings. Bill Wood established Wilwood Engineering in 1977, and the company is based in Camarillo, California. It designs and manufactures disc brake systems, including calipers, brake rotors, master cylinders, valves, fittings and brake lines, for motorsport, street-performance and specialized use. The individual parts must be selected as compatible elements of the complete brake system.
Technical Details
- Manufacturer part number: 220-12782
- Component: Brake flexline and fitting kit
- Hose length (inches): 16.00
- Line or fitting size: -3
- Chassis adapter connection: -3 to 7/16-24 inverted flare
- Hose inlet connection: -3 Female
- Hose outlet connection: -3 Female
- Caliper adapter angle: 90 Degree
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-13125
- Hose quantity: 2
Fitment & Compatibility
Match the exact early Oldsmobile conversion rather than choosing by model year alone. The photograph shows an angled hose end, while the fitting fields identify straight ends; confirm the delivered hose-end geometry before installation.
Manufacturer Documents
With more than 20 years of experience, PMB Performance can assist with brake-component selection. Provide the vehicle and installed brake details so the connection and mounting requirements can be checked together.
