Product details
The early Mustang kit lists two imperial chassis-adapter sizes so the installed hard-line connection can be matched correctly. Two 18-inch braided hoses connect those inverted-flare adapters to separate 90-degree NPT caliper elbows. Wilwood Engineering’s work covers the design and manufacture of disc brake systems for motorsport, street-performance and specialized applications. Bill Wood founded the company in 1977 in a business now based in Camarillo, California. Its calipers, master cylinders, brake rotors, brake lines, valves and fittings must be selected around the complete system.
Technical Details
- Manufacturer part number: 220-12168
- Component: Brake flexline and fitting kit
- Hose length (inches): 18.00
- Line or fitting size: -3
- Chassis adapter connection: -3 to 3/8-24 inverted flare or 7/16-24 inverted flare
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Caliper adapter angle: 90 Degree
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-13125
- Chassis adapter reference: 220-13124 / 220-6457
- Chassis retaining clip reference: 300-15780
- Line support reference: 250-12636
- Hose quantity: 2
- Listed weight: 0.800 lb
Fitment & Compatibility
For the specified 1965–1969 Mustang front conversion. Confirm whether the chassis uses 3/8-24 or 7/16-24 inverted flare, then check the listed bracket arrangement and steering clearance.
