Product details
This Factory Five rear package links the CPB caliper's banjo inlet to domestic inverted-flare chassis plumbing. Its 16-inch lines use a right-angle outlet hose end, separating the rear caliper connection from the front DP6 layout. From Camarillo, California, Wilwood Engineering designs and manufactures disc brake systems and their components. Founded by Bill Wood in 1977, it serves street-performance, motorsport and specialized applications with master cylinders, calipers, brake rotors, valves, fittings and brake lines. All components must suit the requirements of the complete system.
Technical Details
- Manufacturer part number: 220-12093
- Component: Brake flexline and fitting kit
- Hose length (inches): 16.00
- Line or fitting size: -3
- Chassis adapter connection: -3 to 3/8-24 inverted flare
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: 90 Degree
- Caliper adapter angle: Banjo, 0 degrees
- Caliper connection: 10mm Banjo
- Caliper adapter reference: 220-10416
- Chassis adapter reference: 220-13124
- Hose quantity: 2
- Listed weight: 0.800 lb
Fitment & Compatibility
Check the Factory Five rear brake package and the CPB mounting location before selecting the hoses. The chassis connection must use the specified 3/8-24 inverted-flare seat.
