Product details
Integrated metric female chassis connections distinguish this 24-inch line pair for Nissan 370Z and Infiniti G37 front conversions. The caliper-side fittings turn through 45 degrees before entering the specified NPT ports. Established in 1977 by Bill Wood, Camarillo, California-based Wilwood Engineering designs and manufactures disc brake systems for motorsport, street-performance and specialized applications. Calipers, brake rotors, master cylinders, valves, fittings and brake lines form its component range, with individual parts chosen to match the complete system rather than considered in isolation.
Technical Details
- Manufacturer part number: 220-11590
- Component: Brake flexline and fitting kit
- Hose length (inches): 24.00
- Line or fitting size: -3
- Hose inlet connection: M10 inverted flare Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Caliper adapter angle: 45 Degree
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-6412
- Hose quantity: 2
- Listed weight: 1.000 lb
Fitment & Compatibility
Select for the listed Superlite 4 or Superlite 6 conversion on the 370Z or G37. Confirm the actual chassis connection and hose attachment points rather than assuming compatibility with the original calipers.
Manufacturer Documents
If the brake system has been modified, contact PMB Performance with the installed component references and routing dimensions. We have more than 20 years of experience helping match brake parts to their applications.
