Product details
The short 10-inch hose pair is arranged for Wilwood CPB rear conversions using domestic-style 3/8-24 inverted-flare chassis plumbing. Separate 10 mm banjo fittings complete the caliper connection while straight -3 female hose ends join the adapters. The manufacturer, Wilwood Engineering, was established by Bill Wood in 1977 and is based in Camarillo, California. It designs and builds disc brake systems with a range covering calipers, brake rotors, master cylinders, valves, fittings and brake lines. Motorsport, street-performance and specialized applications require components selected for the complete braking system.
Technical Details
- Manufacturer part number: 220-10685
- Component: Brake flexline and fitting kit
- Hose length (inches): 10.00
- Line or fitting size: -3
- Chassis adapter connection: -3 to 3/8-24 inverted flare
- Hose inlet connection: -3 Female
- Hose inlet angle: Straight
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Caliper adapter angle: Banjo, 0 degrees
- Caliper connection: 10mm Banjo
- Caliper adapter reference: 220-10416
- Chassis adapter reference: 220-13124
- Chassis retaining clip reference: 300-15780
- Hose quantity: 2
- Listed weight: 0.800 lb
Fitment & Compatibility
This is a conversion-kit hose arrangement, not a claim that every domestic rear axle shares its routing. Confirm the CPB caliper, chassis flare seat and suspension travel required by the installation.
