Product details
A 90-degree male 3/8-24 chassis end distinguishes these rear Corvette hoses from lines that use a separate female chassis adapter. The pair is intended for the specified Superlite 4 rear conversion and includes the caliper-side NPT adapters. Wilwood Engineering has designed and manufactured disc brake systems since Bill Wood founded it in 1977. Its Camarillo, California operation supplies calipers, master cylinders, brake rotors, valves, fittings and lines for specialized, street-performance and motorsport applications. Each component must be chosen to match the complete brake system.
Technical Details
- Manufacturer part number: 220-10632
- Component: Brake flexline and fitting kit
- Hose length (inches): 10.50
- Line or fitting size: -3
- Hose inlet connection: 3/8-24 Male
- Hose inlet angle: 90 Degree
- Hose outlet connection: -3 Female
- Hose outlet angle: Straight
- Caliper adapter angle: 90 Degree
- Caliper connection: 1/8-27 NPT
- Caliper adapter reference: 220-13125
- Hose quantity: 2
- Listed weight: 0.800 lb
Fitment & Compatibility
Match the 1965–1982 Corvette rear conversion identified as BNSL4R in Wilwood's kit notes. Verify the chassis fitting's seat and the required 10.5-inch route before installation.
Manufacturer Documents
Use PMB Performance's 20-plus years of experience when checking uncertain fitment. Identify the actual hose ends, port seats and brake package as well as the vehicle before ordering.
