Product details
The Wilwood Powerlite replacement has a 1.00-inch outside diameter and 0.820-inch published length. Check the caliper body, seal and piston cavity. Wilwood Engineering is a Camarillo, California manufacturer founded by Bill Wood in 1977. Disc brake design and manufacturing extend across calipers, brake rotors, master cylinders, valves, fittings and brake lines. Parts for street-performance, specialized applications and motorsport must be selected to meet the requirements of the complete brake system.
Technical Details
- Manufacturer part number: 200-12952
- Outside diameter: 1.00 inches
- Overall length: 0.820 inches
- Piston construction: Cast
- Material: Stainless
Fitment & Compatibility
Match the existing piston and caliper documentation, including the overall depth and sealing arrangement. Vehicle make and model cannot identify this internal component on a modified brake system. This is the cast stainless piston configuration. Check its complete shape and hydraulic seal compatibility against the manufacturer’s caliper parts information.
Manufacturer Reference
Wilwood component specifications and dimensions
Ask PMB Performance for help comparing the installation requirements. We have more than 20 years of experience working with brake parts and fitment.
