Product details
Wilwood's Veloster front hat uses twelve lugs on an 8.80-inch circle. Confirm the specific brake kit, 0.490-inch offset and 2.72-inch register. Since its founding by Bill Wood in 1977, Wilwood Engineering has focused on disc brake system design and manufacturing. Based in Camarillo, California, it offers calipers, rotors, brake lines, master cylinders, fittings and valves for motorsport, street-performance and specialized installations. Choose components to satisfy the requirements of the entire braking system.
Technical Details
- Manufacturer part number: 170-15977
- Surface finish: Type III Anodize
- Rotor mounting method: Dynamic Lug Mount
- Position in the specified brake assembly: Front
- Hat offset: 0.490 inch
- Rotor attachment interface: 12lug-8.80 inches; drive-lug connection, not a wheel bolt pattern
- Hub-flange mounting/clearance pattern(s): 5 x 4.50 inches; verify the actual hub and wheel-stud clearance
- Center register diameter: 2.72 inches
- Internal clearance diameter: 8.20 inches
- Mounting-face thickness: 0.31 inches
- Hub-side hole clearance diameter(s): 0.500 inches; these are clearance dimensions, not wheel-stud thread sizes
- Manufacturer-listed attachment hardware reference: 300-14913; verify the specific rotor and attachment arrangement before ordering hardware
- Manufacturer installation note: 300-14913 Dynamic Lug Mount Clip & Snap Ring kit are required for rotor mounting.
- Component: Lug-Drive Rotor Hat
- Material: Aluminum
Fitment & Compatibility
This is a component for Hyundai Veloster brake conversions, not a complete brake kit. Check the hub location, rotor mounting surface and caliper alignment as a system before ordering. Use the specified lug-drive friction ring and clip/snap-ring retention system. A conventional bolt-on ring is a different attachment arrangement.
Manufacturer Reference
Wilwood component specifications and dimensions
With more than 20 years of parts and fitment experience, PMB Performance can help compare the existing brake assembly with the required component.
