Product details
Ten mounting holes distinguish this 12.90-inch GT rotor from the eight- and twelve-bolt families. The right-hand Spec-37 ring uses a nominal 1.26-inch section, with 48 curved vanes and slotted friction faces. Wilwood began in 1977 with founder Bill Wood and is based in Camarillo, California, where it designs and manufactures disc brake systems. Calipers and rotors sit alongside master cylinders, valves, fittings and lines in a range serving motorsport, street performance and specialized applications. Selecting these parts together is essential to a correctly matched brake installation.
Technical Details
- Manufacturer part number: 160-7137
- Quantity: One rotor; not an axle pair
- Outside diameter: 12.90 inches
- Nominal thickness: 1.26 inches
- Rotor material: Spec-37 Iron
- Construction: 48 curved vanes
- Friction surface: GT Slotted
- Finish: Plain
- Approximate weight: 14.30 lb
- Factory burnished: No
- Dynamically balanced: Yes
- Installation orientation: Right-hand
- Rotor attachment pattern: 10 x 8.11 inches
- Rotor mounting hole / thread: 0.316 inches
- Registration / lug inside diameter: 7.24 inches
- Far-side inside diameter: 8.66 inches
- Opposite-hand companion rotor: 160-7138 (sold separately)
- Intended use and restrictions: Suitable for moderate-temperature racing and street use. Spec-37 heavy-wall castings.
The hat or hub, fasteners, caliper and pads are not included.
Fitment & Compatibility
Match the 8.11-inch attachment circle, 0.316-inch holes and 7.24-inch register. The number and spacing of rotor fasteners are independent of the vehicle’s wheel pattern.
