Product details
Extensive race drilling distinguishes this 0.81-inch Ultralite ring from the street-oriented SRP surface pattern. Its 11.75-inch iron casting uses 32 vanes and is intended for the light-to-moderate dirt-racing duty specified by Wilwood. A rotor must suit both the mechanical installation and the rest of the braking system. Wilwood brings that system perspective to its calipers, rotors, master cylinders, valves, fittings and lines, designing and manufacturing disc brake systems for motorsport, street performance and specialized applications. Bill Wood founded the Camarillo, California company in 1977.
Technical Details
- Manufacturer part number: 160-5863
- Quantity: One rotor; not an axle pair
- Outside diameter: 11.75 inches
- Nominal thickness: 0.81 inches
- Rotor material: Iron
- Construction: 32 vanes
- Friction surface: Race Drilled
- Finish: Plain
- Approximate weight: 7.20 lb
- Factory burnished: No
- Dynamically balanced: No
- Installation orientation: Non-directional
- Rotor attachment pattern: 8 x 7.00 inches
- Rotor mounting hole / thread: 0.326 inches
- Registration / lug inside diameter: 6.38 inches
- Far-side inside diameter: 8.34 inches
- Intended use and restrictions: For light to moderate dirt racing. Race-drilled rotors are unsafe for street use and can fail if misused.
The hat or hub, fasteners, caliper and pads are not included.
Fitment & Compatibility
Unsafe for street use; misuse can cause failure. Confirm the exact racing application, eight-on-7.00-inch mount and 6.38-inch register before use.
Wilwood product specifications · Rotor dimension diagram
